    Flanged Dowel Box Kits are multi-directional metal sleeves supplied with high capacity square dowels. They are can be attached to metal or wooden formwork with ease with their integral nailing flanges and location marks.

    They allow for both contraction and expansion at the joint, as well as having a large lateral movement capacity. Flanged Dowel Boxes are ideal for construction joints in slab-on-ground applications and are available in a number of different standard sizes.

    The Flanged Dowel Box Kits can also be used when installing dowels into existing heavy-duty slabs, when square dowels greater than 25mm are required.


    • Integral nailing flange for fast fit attachment to formwork.
    • Chalk line marks are integrated in the flange to mark centre-line position.
    • Large lateral movement capacity (minimum of 20mm either side of the dowel).
    • Large expansion joint capacity (20mm standard).
    • Supplied in kit form with a friction cut square dowel to AS/NZS 3679.1, Grade 300.
    • Galvanised Box with Black or Galvanised Dowels.
    • Suits 16mm to 32mm square dowels.


    • Designed for Post Tension joint applications with large shrinkage.
    • Allows for movement in two directions in the horizontal plane.
    • Reduces risk of restraint.
    • Simple nail or screw-on installation..
    • Eliminates the need to drill or process formwork.
    • Reduced likelihood of sleeve knock-off when placing steel reinforcement mesh.
