Trench Mesh Supports

RRP $0.00
    • Description
    • Features


    Danley™ Trench Mesh Supports are designed to suit typical trench mesh and reinforcement bar sizes used in edge beams. Trench Mesh Supports are stable and provide excellent support to mesh resulting in uniformed concrete cover. Able to clip-on to the mesh they allow the support to be fitted prior to lowering mesh into a trench. They can also be used in strip footings and raft slabs. They have flat feet ensuring that there are no sharp edges that could pierce the membrane.

    Clip-on: The Trench Mesh Support allows for an easy clip-on function when attaching it to reinforcing. This facilitates a quicker installation time and improves the ease of use. The clip-on function also allows the trench reinforcing to be set up as an assembled cage outside of the slab easily dropped in at installation. Four types of Trench Mesh Support are available each with different clip-on features for different types of reinforcing bars.




    Features:

    • Trench mesh Supports are available in four configurations.
    • Strong and stable design.
    • Secure support for 8mm, 11mm, 12mm and 16mm reinforcing bar or mesh.
    • Easy to use clip-on design makes steel placement simple.
    • 60mm chair for edge beam reinforcing bars.
    • Large aperture design facilitates continuous, uninterrupted and consistent concrete coverage.
    • No sharp edges or corners on the base, minimising the likelihood of ground moisture penetrating the membrane.
    • Flat feet designed to work with plastic waterproofing film.
    • Complies with the requirements of AS/NZS 2425:2015.
    • Australian Made. The ramsetreid® manufacturing facility at Chirnside Park (Victoria) is ISO 9001 certified.




    Trench Mesh Supports for 8-12mm Bar

    Trench Mesh Supports for 8-12mm Bar:

    Part #DescriptionAS2425 Load Rating
    (kg)
    Pack qty
    (Each)
    Pallet qty
    (pack)
    Pallet qty
    (Each)
    Pallet HeightPallet M3A (mm)B (mm)C
    (mm)
    Max bar size
    BCTMSTrench Mesh Supports for 8-12mm Bar60251203,0001,0501.5160290up to 12mm
    Trench Mesh Supports for 16mm Bar

    Trench Mesh Supports for 16mm Bar:

    Part #DescriptionAS2425 Load Rating
    (kg)
    Pack qty
    (Each)
    Pallet qty
    (pack)
    Pallet qty
    (Each)
    Pallet HeightPallet M3A (mm)B (mm)C
    (mm)
    Max bar size
    BCTMS016Trench Mesh Supports for 16mm Bar60251203,0001,0501.5160290up to 16mm
    Trench Mesh Support Edge Beam Spacer 300mm

    Trench Mesh Support Edge Beam Spacer 300mm:

    Part #DescriptionAS2425 Load Rating
    (kg)
    Pack qty
    (Each)
    Pallet qty
    (pack)
    Pallet qty
    (Each)
    Pallet HeightPallet M3A (mm)B (mm)C
    (mm)
    Max bar size
    BCTMSEB300Trench Mesh Support Edge Beam Spacer 300mm60251203,0001,0501.5160300up to 16mm
